The powerhouse model of the Wharfedale DIAMOND 12 series, the DIAMOND 12.4 is the room-filling, chest-pounding, largest model in the series.
For larger, more powerful systems and cinema-style home theatre experiences, the DIAMOND 12.4 will fill your room with an impactful, immersive performance.
Configured in a 2.5 way system with exception crossover technology, the DIAMOND 12.3 utilises dual 150mm (6.5”) KlarityTM drivers for impactful yet refined mid-range and bass frequencies, while the 25mm (1”) dome tweeter delivers open and smoothly extended high frequencies.
Specifications
| General description | 2.5-way floorstanding speaker |
|---|---|
| Enclosure type | bass reflex |
| Bass driver | 6.5″(150mm) advanced PP Cone |
| Midrange driver | 6.5″(150mm) advanced PP Cone |
| Treble driver | 1″(25mm) Textile Dome |
| AV shield | No |
| Sensitivity(2.83V @ 1m) | 89dB |
| Recommended amplifier power | 30-200W |
| Peak SPL | 102dB |
| Nominal impedance | 8Ω Compatible |
| Minimum impedance | 5Ω |
| Frequency response(+/-3dB) | 40Hz ~ 20kHz |
| Bass extension(-6dB) | 35Hz |
| Crossover frequency | 2.1kHz |
| Cabinet Volume (in litres) | 40.8L |
| Dimensions ( H x W x D ) | (1100+50) x 200 x (350+28) mm |
| Net weight | 22.4kg/pcs |
